为多租户 Spark 集群构建基于 Tonic 的即时 IAM 凭证颁发服务

IAM gRPC Rust Apache Spark Tonic
分布式系统
文章字数:   3.2k
阅读时长:   15 分

在管理一个共享的、多租户的 Apache Spark 集群时，数据访问的权限控制是一个无法回避的核心挑战。当不同的租户作业需要在隔离的 S3 存储桶中读写数据时，如何安全、动态地为其授予最小权限，同时避免凭证泄露，成为架构设计的关键。一个常见的错误是将长期有效的 AWS Access Key 硬编码在 Spark 配置中，或者为整个集群配置一个过于宽泛的 IAM Instance Profile。这两种方式都严重违反了最小权限原则，在生产环境中是不可接受的。

架构决策的十字路口摆着两个看似可行的方案：利用云原生生态的原生集成，或是构建一个专用的凭证管理微服务。

方案 A: EKS IAM Roles for Service Accounts (IRSA)

在 Kubernetes 上运行 Spark 的场景中，IRSA 是一个常见的首选方案。它通过将 Kubernetes Service Account 与 AWS IAM Role 关联，允许 Pod 内的应用程序通过 OIDC 联邦认证，自动获取临时 IAM 凭证。

graph TD
    subgraph Kubernetes Cluster
        A[Spark Driver Pod] -- "K8s SA Token" --> B(OIDC Provider);
        A -- "Uses ServiceAccount `spark-job-sa`" --> C{K8s Service Account};
        C -- "Annotated with `eks.amazonaws.com/role-arn`" --> D((IAM Role));
    end
    B -- "Validates Token" --> E(AWS STS);
    E -- "AssumeRoleWithWebIdentity" --> F[Temporary IAM Credentials];
    F -- "Returns Credentials" --> A;
    A -- "Uses Credentials" --> G[ Tenant S3 Bucket];

优势分析:

  1. 原生集成: 与 EKS 紧密集成，配置相对直接，无需额外部署服务。
  2. 无长期凭证: 遵循最佳实践，使用短期的临时凭证，自动轮换。

劣势分析:

  1. 粒度问题: IRSA 的权限是绑定到 Service Account 上的。在一个多租户 Spark 平台，如果为每个租户的每个作业都动态创建一个独立的 Service Account，会带来巨大的管理开销。如果多个租户作业共享同一个 Service Account，它们就会获得相同的 IAM Role，这又回到了权限过于宽泛的问题。我们无法做到“作业级别”的精细化权限控制。
  2. 灵活性不足: 权限策略是静态地附加在 IAM Role 上的。如果需要根据作业的特定参数（例如，只允许访问 s3://tenant-bucket/input-path/*）动态生成更细粒度的策略，IRSA 无法直接满足。
  3. Spark Executor 问题: Spark 的 Driver 和 Executor 可能运行在不同的 Pod 中。虽然可以通过 spark.kubernetes.executor.serviceAccountName 为 Executor 指定 Service Account，但这进一步加剧了管理复杂性。

在真实的多租户场景下，租户 A 的作业绝不应该有任何可能性访问租户 B 的数据。IRSA 在这种严格隔离模型下显得力不从心。

方案 B: 构建独立的凭证颁发服务 (Token Vending Machine)

此方案的核心是创建一个独立的、高可用的微服务，我们称之为“凭证贩卖机”（Token Vending Machine, TVM）。这个服务本身拥有一个权限相对较大的 IAM Role，使其能够调用 AWS STS 的 AssumeRole API。Spark 作业启动时，其 Driver 和 Executor 会通过一个安全的 gRPC 通道向 TVM 发起请求，获取仅限于自身任务所需范围的、生命周期极短的临时凭证。

graph TD
    subgraph Spark Application
        SD[Spark Driver] -->|1. gRPC Request| TVM;
        SE[Spark Executor] -->|1. gRPC Request| TVM;
    end

    subgraph Secure Infrastructure
        TVM(Credential Service - TVM) -- "Has powerful IAM Role" --> STS;
    end

    TVM -- "2. Authenticates Request (e.g., via JWT)" --> TVM;
    TVM -- "3. sts:AssumeRole with dynamic policy" --> STS(AWS STS);
    STS -- "4. Returns Scoped Temporary Credentials" --> TVM;
    TVM -- "5. Returns Credentials via gRPC" --> SD;
    TVM -- "5. Returns Credentials via gRPC" --> SE;

    SD -- "6. Uses Credentials" --> S3[ Tenant S3 Bucket];
    SE -- "6. Uses Credentials" --> S3;

优势分析:

  1. 极致的权限控制: TVM 可以在运行时，根据请求方（租户ID、作业ID、目标路径等）动态生成一个内联的 IAM Policy。这意味着可以为每个 Spark Task 颁发“恰好够用”的权限，完美实现最小权限原则。
  2. 逻辑集中与解耦: 权限生成的复杂逻辑被封装在 TVM 内部。Spark 作业本身无需关心 IAM 的复杂性，只需知道如何调用 TVM 即可。这种解耦使得权限策略的迭代和审计变得非常简单。
  3. 技术栈无关性: 任何需要访问 AWS 资源的应用都可以复用 TVM，不仅仅是 Spark。

劣势分析:

  1. 引入新组件: 需要额外开发、部署和维护一个高可用的服务。TVM 成为系统的关键路径，其稳定性和性能至关重要。
  2. 实现复杂度: 需要自行处理认证、授权、调用 STS、缓存、错误处理等逻辑。

考虑到我们平台对安全性和租户隔离的严苛要求，方案 B 尽管增加了初始开发成本，但其提供的精细化控制和长期可维护性是 IRSA 无法比拟的。我们最终选择基于 Rust 和 Tonic 构建这个高性能、内存安全的 TVM 服务。Rust 的安全保障和 Tonic 框架的性能表现，使其成为构建这类安全核心组件的理想选择。

核心实现：Tonic 凭证服务与 Spark 自定义 Provider

整个实现分为两大部分：使用 Tonic (Rust) 构建的 gRPC 服务端，以及一个 Spark 可以加载的自定义 AWSCredentialsProvider (Scala) 作为客户端。

1. 定义 gRPC 服务接口 (credentials.proto)

首先，我们用 Protobuf 定义服务接口。请求中包含必要的上下文信息，用于动态生成策略。响应则直接映射到 AWS 的临时凭证结构。

syntax = "proto3";

package credentials.v1;

// The core credential vending service.
service CredentialService {
  // Requests short-lived, scoped-down AWS credentials.
  rpc GetScopedCredentials(GetScopedCredentialsRequest) returns (GetScopedCredentialsResponse) {}
}

message GetScopedCredentialsRequest {
  // Identifier for the tenant, extracted from the request's authentication token (e.g., JWT).
  // This field is for context, the primary identity is verified from the token.
  string tenant_id = 1;

  // The specific S3 path the job needs to access.
  // Example: "s3://my-tenant-bucket/data/2023-10-27/"
  string resource_path = 2;

  // The duration for which the credentials should be valid, in seconds.
  // The service will enforce a maximum duration.
  int32 duration_seconds = 3;
}

message GetScopedCredentialsResponse {
  string access_key_id = 1;
  string secret_access_key = 2;
  string session_token = 3;
  // Expiration timestamp in UTC seconds since epoch.
  int64 expiration = 4;
}

2. Tonic 服务端实现 (tvm-server/src/main.rs)

这是 TVM 的核心。它监听 gRPC 请求，验证调用方身份，然后调用 AWS STS API 生成凭证。

// File: tvm-server/src/main.rs

use tonic::{transport::Server, Request, Response, Status};
use credentials::v1::{
    credential_service_server::{CredentialService, CredentialServiceServer},
    GetScopedCredentialsRequest, GetScopedCredentialsResponse,
};
use aws_sdk_sts::Client as StsClient;
use aws_config::meta::region::RegionProviderChain;
use std::time::Duration;
use tracing::{info, warn, error};
use tracing_subscriber;

// Proto-generated module
pub mod credentials {
    pub mod v1 {
        tonic::include_proto!("credentials.v1");
    }
}

// Configuration loaded from environment variables or a config file
#[derive(Debug)]
struct Config {
    aws_role_arn_to_assume: String,
    max_duration_seconds: u32,
    listen_addr: String,
}

#[derive(Debug)]
pub struct MyCredentialService {
    sts_client: StsClient,
    config: Config,
}

impl MyCredentialService {
    // Helper function to create a dynamically scoped IAM policy.
    // In a real project, this should use a proper JSON builder to avoid injection risks.
    fn create_scoped_policy(&self, resource_path: &str) -> Result<String, Status> {
        // Basic validation: ensure it's a valid S3 path format.
        if !resource_path.starts_with("s3://") {
            warn!("Invalid resource_path format: {}", resource_path);
            return Err(Status::invalid_argument("resource_path must start with s3://"));
        }

        let parts: Vec<&str> = resource_path.trim_start_matches("s3://").splitn(2, '/').collect();
        let bucket = parts.get(0).ok_or_else(|| Status::invalid_argument("Invalid S3 path: missing bucket"))?;
        let key_pattern = parts.get(1).map_or("*", |p| if p.is_empty() { "*" } else { &format!("{}*", p) });

        let policy = serde_json::json!({
            "Version": "2012-10-17",
            "Statement": [
                {
                    "Effect": "Allow",
                    "Action": [
                        "s3:GetObject",
                        "s3:PutObject",
                        "s3:DeleteObject",
                        "s3:ListBucket" // List is on the bucket, not the object
                    ],
                    "Resource": [
                        format!("arn:aws:s3:::{}/*", bucket), // Grant access to objects
                        format!("arn:aws:s3:::{}", bucket)     // Grant access to the bucket itself for ListBucket
                    ]
                }
            ]
        });

        Ok(policy.to_string())
    }
}

#[tonic::async_trait]
impl CredentialService for MyCredentialService {
    async fn get_scoped_credentials(
        &self,
        request: Request<GetScopedCredentialsRequest>,
    ) -> Result<Response<GetScopedCredentialsResponse>, Status> {
        info!("Received credential request");

        // --- 1. Authentication ---
        // In a real system, you'd extract a JWT from request metadata and validate it.
        // The JWT's claims would contain the tenant_id, preventing spoofing.
        // For this example, we trust the tenant_id from the request payload.
        // let tenant_id = self.authenticate(request.metadata())?;
        let inner_req = request.into_inner();
        let tenant_id = inner_req.tenant_id;

        if tenant_id.is_empty() {
             return Err(Status::unauthenticated("Missing tenant_id"));
        }

        // --- 2. Authorization & Validation ---
        let duration = inner_req.duration_seconds.min(self.config.max_duration_seconds as i32);
        if duration < 900 { // AWS STS minimum is 900 seconds
            return Err(Status::invalid_argument("Duration must be at least 900 seconds"));
        }

        // --- 3. Generate Dynamic Policy ---
        let policy_json = self.create_scoped_policy(&inner_req.resource_path)?;
        info!("Generated policy for tenant '{}' and path '{}'", tenant_id, inner_req.resource_path);

        // --- 4. Assume Role with AWS STS ---
        let role_session_name = format!("spark-job-{}-{}", tenant_id, chrono::Utc::now().timestamp_millis());

        // Ensure session name is valid
        let role_session_name: String = role_session_name.chars().filter(|c| c.is_ascii_alphanumeric() || *c == '_' || *c == '.' || *c == '@' || *c == '-').collect();
        if role_session_name.len() > 64 {
            role_session_name.truncate(64);
        }

        let assume_role_output = self.sts_client
            .assume_role()
            .role_arn(&self.config.aws_role_arn_to_assume)
            .role_session_name(role_session_name)
            .policy(policy_json)
            .duration_seconds(duration)
            .send()
            .await
            .map_err(|e| {
                error!("STS AssumeRole failed: {}", e);
                Status::internal("Failed to assume AWS role")
            })?;

        // --- 5. Construct and Send Response ---
        if let Some(creds) = assume_role_output.credentials {
            let expiration = creds.expiration.unwrap().as_secs_f64() as i64;
            let response = GetScopedCredentialsResponse {
                access_key_id: creds.access_key_id.unwrap_or_default(),
                secret_access_key: creds.secret_access_key.unwrap_or_default(),
                session_token: creds.session_token.unwrap_or_default(),
                expiration,
            };
            info!("Successfully issued credentials for tenant '{}'", tenant_id);
            Ok(Response::new(response))
        } else {
            error!("STS response was successful but contained no credentials.");
            Err(Status::internal("Invalid response from AWS STS"))
        }
    }
}

#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
    tracing_subscriber::fmt::init();

    // In production, load from a secure source.
    let config = Config {
        aws_role_arn_to_assume: std::env::var("AWS_ROLE_ARN_TO_ASSUME")
            .expect("AWS_ROLE_ARN_TO_ASSUME must be set"),
        max_duration_seconds: 3600, // 1 hour max
        listen_addr: "0.0.0.0:50051".to_string(),
    };

    let region_provider = RegionProviderChain::default_provider().or_else("us-east-1");
    let aws_config = aws_config::from_env().region(region_provider).load().await;
    let sts_client = StsClient::new(&aws_config);

    let addr = config.listen_addr.parse()?;
    let service = MyCredentialService { sts_client, config };

    info!("Credential Service listening on {}", addr);

    Server::builder()
        .add_service(CredentialServiceServer::new(service))
        .serve(addr)
        .await?;

    Ok(())
}

3. Spark 自定义凭证 Provider (TvmCredentialProvider.scala)

这个 Scala 类将作为 Spark 作业的一部分被打包。它实现了 Hadoop 的 AWSCredentialsProvider 接口，在需要凭证时，它会调用我们的 TVM 服务。

// File: TvmCredentialProvider.scala

package com.mycompany.spark.auth

import com.amazonaws.auth.{AWSCredentials, AWSCredentialsProvider, BasicSessionCredentials}
import com.mycompany.credentials.v1.CredentialServiceGrpc
import com.mycompany.credentials.v1.GetScopedCredentialsRequest
import io.grpc.{ManagedChannel, ManagedChannelBuilder}
import org.apache.hadoop.conf.Configuration
import java.net.URI
import java.util.concurrent.TimeUnit
import org.slf4j.LoggerFactory

class TvmCredentialProvider(uri: URI, conf: Configuration) extends AWSCredentialsProvider {

  private val logger = LoggerFactory.getLogger(classOf[TvmCredentialProvider])

  private val TVM_ADDRESS_KEY = "fs.s3a.custom.tvm.address"
  private val TVM_TENANT_ID_KEY = "fs.s3a.custom.tvm.tenant.id"
  private val TVM_RESOURCE_PATH_KEY = "fs.s3a.custom.tvm.resource.path"

  private val tvmAddress: String = conf.get(TVM_ADDRESS_KEY, "localhost:50051")

  // A real implementation would cache credentials until they are close to expiring.
  // This simple version fetches new credentials on every call to getCredentials().
  // Using `Option` and `synchronized` is crucial for thread safety.
  @volatile private var cachedCredentials: Option[(BasicSessionCredentials, Long)] = None

  private def createGrpcChannel(): ManagedChannel = {
    ManagedChannelBuilder.forTarget(tvmAddress).usePlaintext().build()
  }

  override def getCredentials: AWSCredentials = {
    synchronized {
      val now = System.currentTimeMillis() / 1000
      // Check if cache is valid (exists and not expiring within the next 5 minutes)
      cachedCredentials match {
        case Some((creds, expiration)) if expiration > now + 300 =>
          logger.debug("Using cached credentials")
          return creds
        case _ =>
          logger.info("Credentials expired or not found, fetching new credentials from TVM.")
          // Fall through to fetch new credentials
      }

      val channel = createGrpcChannel()
      try {
        val tenantId = conf.get(TVM_TENANT_ID_KEY, "")
        // We get the resource path from the URI being accessed.
        // This is a simplification; a more robust solution might need more context.
        val resourcePath = s"s3://${uri.getHost}${uri.getPath}"

        if (tenantId.isEmpty) {
          throw new RuntimeException(s"Hadoop config key '$TVM_TENANT_ID_KEY' must be set.")
        }

        logger.info(s"Requesting credentials for tenant '$tenantId' and path '$resourcePath'")

        val stub = CredentialServiceGrpc.newBlockingStub(channel)
        val request = GetScopedCredentialsRequest.newBuilder()
          .setTenantId(tenantId)
          .setResourcePath(resourcePath)
          .setDurationSeconds(3600) // Request 1-hour credentials
          .build()

        val response = stub.getScopedCredentials(request)

        val newCreds = new BasicSessionCredentials(
          response.getAccessKeyId,
          response.getSecretAccessKey,
          response.getSessionToken
        )

        // Cache the new credentials with their expiration time
        cachedCredentials = Some((newCreds, response.getExpiration))
        newCreds

      } catch {
        case e: Exception =>
          logger.error("Failed to get credentials from TVM", e)
          throw new RuntimeException("Failed to retrieve credentials from TVM service", e)
      } finally {
        channel.shutdownNow().awaitTermination(5, TimeUnit.SECONDS)
      }
    }
  }

  override def refresh(): Unit = {
    // Force invalidation of the cache
    synchronized {
      cachedCredentials = None
    }
    logger.info("Credentials cache invalidated by refresh() call.")
  }
}

最后，在提交 Spark 作业时，通过配置来启用这个 Provider：

spark-submit \
  --class com.mycompany.Main \
  --conf "spark.hadoop.fs.s3a.aws.credentials.provider=com.mycompany.spark.auth.TvmCredentialProvider" \
  --conf "spark.hadoop.fs.s3a.custom.tvm.address=tvm-service.my-namespace:50051" \
  --conf "spark.hadoop.fs.s3a.custom.tvm.tenant.id=tenant-a" \
  --jars my-spark-app.jar,grpc-stub.jar,custom-provider.jar \
  my-spark-app.jar

这里的核心在于 fs.s3a.aws.credentials.provider 配置，它告诉 Hadoop S3A 文件系统使用我们的自定义类来获取凭证。

架构的局限性与未来展望

这个 TVM 架构虽然解决了精细化权限控制的核心问题，但并非银弹。首先，TVM 服务自身的高可用性至关重要。生产环境必须部署多个 TVM 实例，并通过负载均衡器对外提供服务。其次，TVM 与 Spark Executor 之间的网络延迟会轻微增加首次数据访问的耗时，尽管 gRPC 的性能和凭证缓存机制可以很大程度上缓解这个问题。

未来的优化路径可以集中在以下几个方面：

  1. 凭证缓存策略: 在 TvmCredentialProvider 中实现更智能的缓存和预取逻辑。例如，在一个凭证过期前的几分钟，异步地去获取下一个凭证，避免作业在关键时刻因等待新凭证而阻塞。
  2. 双向 TLS (mTLS): 为了增强安全性，TVM 与客户端之间的通信应启用 mTLS，确保只有受信任的 Spark 作业才能请求凭证。
  3. 支持多云: 将 TVM 的核心逻辑抽象化，使其可以作为一个插件式平台，不仅支持 AWS STS，还能对接 Google Cloud IAM 和 Azure Active Directory，为跨云数据处理提供统一的凭证管理入口。
  4. 审计与监控: 对每一次凭证请求和颁发都生成详细的、结构化的日志，并接入监控系统。这对于安全审计和排查问题至关重要。
IAM gRPC Rust Apache Spark Tonic
  目录
